Table Height
Table height is 29" to 30" depending on table top specified.
Column
Column made of 1.5" x 3", 11 gauge OVAL tubular steel and notched to accept base plate.
Base
2" round 14 gauge – 16", 22" and 26" spreads.
Endcaps are steel stamped discs, all hand brazed welded and polished smooth.
Plate Top plate is 0.25" thick by 6" x 18", or 6" x 24" stamped steel, depending on size of tabletop.
Glides Factory installed adjustable zinc rubber cushion steel glides are standard.
Modesty
Panels Steel Modesty Panel is 14 gauge perforated steel.
Laminate Modesty Panel is 0.75" thick by 10" high by the length of the table top. Modesty panel is covered with laminate and finished with choice of edge.
Assembly
Base is a completely welded one piece base, no tierod assembly. The top plate is welded to the vertical column and the vertical column is welded to the horizontal base plate. Modesty panels in perforated steel or laminate are attached to OVAL columns with machine screws in metal inserts, no self tapping screws are used. Base mounts to tabletop with ¼-20 x 1"machine screws into metal inserts in top; Stretcher steel bars are used on tops 72" and longer. NO WOOD SCREWS ARE USED.
Finish
Choice of standard powder coat colors – See "Color Selections" brochure
